Product Name: Digital DVB-T Scart Receiver Item No: 1229212949414 U.Price: FOB ShenZhen IN China($) Negotiable Payment: T/T 92157

Description: H.264 Digital DVB-T Compliant
Support MPEG1/2/4 H.264 HD format,DRM support
USB2.0(High speed) ,support USB-OTG
Support 1080i High Definition video(HDMI socket) output
Electronic Program Guide(EPG) and channel editing
Subtitle & Teletext Support
Input/Output Sockets:
HDMI V1.1 output
Composite video output
SPDIF Coaxial digital audio output
Full Scart output (optional)
DVB-T RF antenna input
Technical parameters:
Power consumption: 18W
Power Source: ~100-260V
Audio Output:
Analogue:2.0+0-1.0Vrms
Digital:0.5 ± 0.1 Vp-p(Coaxial)
Max sampling rate:24bit/192KHz
Frequence Response: 20Hz-20KHz( at 1KHz 0 dB)
Signal/noise Ratio(Audio):≥90 dB( at 1KHz 0 dB)
Distortion(Audio):≤-60 dB ( at 1KHz 0dB)
Channel Separation 1KHz: ≥80 dB(Mixed Output)
Dynamic Range: ≥80 dB
Video Output:
Composite:1.0±0.2Vp-p
Load impedance: 75Ω, imbalance, negative polarity
Max Resolution: 1080i(HDMI output)
RGB:700±140mV p-p, 75Ω
(Two panel optional)
